AIRAM PNEUMATIC FOUR POST PRESS – 30314

15 Ton AIRAM PulsAir No. PA15-0101, 4-Post, 3″ Max. Stroke, 14.5″ Die Height, 35″ x 25″ Bed, 2006, Excellent

MODEL: PulsAir PA15-0101
SERIAL NUMBER: 7001-PA15-0101   Year: 2006

“The Pulsair model press offers a manually set adjustable stroke from .25″ to 3″ in .006″ increments.”

Note: Press originally manufactured in March of 2006 exhibited at the Metalform Show in Nashville, TN. Purchased by John A. Logan College for use in their stamping & technology  fields. Primarily used for testing of dies built by students.

GENERAL SPECIFICATIONS

Holding Tonnage @ 100 psi/.5″ – 1″ Stroke: 15 Tons
Holding Tonnage @ 100 psi/2″ Stroke: 14 Tons
Holding Tonnage @ 100 psi/3″ Stroke: 13 Tons
Impact Tonnage: 2 x Holding Tonnage
Die Open Height: 14.50″
Bed Size: 35″ x 25″
Usable Die Space Area: 25″ x 19.7″
Distance Between Guide Pins: 25″ x 15″
Standard Strokes Per Minute @ 3″ Stroke: 90
Standard Strokes Per Minute @ 2″ Stroke: 110
Standard Strokes Per Minute @ 1″ Stroke: 220
Standard Strokes Per Minute @ 1/2″ Stroke: 500
Floor To Top Of Bed With Mounts: 33-1/4″
Input Voltage: 110 Volt, 1 Phase

EQUIPPED WITH

Control Pedestal Including: Two Hand Run/Cycle Buttons, Off/Manual/Continuous Selector Switch,   Top Stop Button, Emergency Stop Button, Strokes Per Minute & Batch Counter
Polycarbonate Die Area Guarding w/Access Door On Front and Rear
Adjustable Stroke Mechanisms
Tie Rod Style Precision Guide Posts
Air Surge Tank (13 Gallon)
(4) Set-up Blocks
Set Of 4 Vibration Mounts
Operation and Instruction Manual

Approximate Weight: 8000 Lbs.

F.O.B. Cincinnati, Ohio

ALL SPECIFICATIONS SUBJECT TO VERIFICATION BY PURCHASER
