WDM INITIAL PINCH HYDRAULIC BENDING ROLL – 30433

6′ x 7/32″ WDM No. B-6-72, Initial, Hyd., 6″ Dia. H & P Rolls, 5 HP, New, In Stock

MODEL: B-6-72
SERIAL NUMBER: 61556-19

GENERAL SPECIFICATIONS

Total Hydraulic Operation
Capacity: 6′ x 7/32″
Diameter Of Rolls: 6″
Rolling Speed: 14 FPM

EQUIPPED WITH

5 HP Drive Motor
Hardened and Polished Rolls 55-60 Rc
Two Roll Hydraulic Drive
Power Bending Roll Adjustment
Cone Attachment
Digital Readout For Bending Roll Position
Circular Grooves: 3/8″, 1/2″, 5/8″
Manually Operated Drop End Collar With Swing Out Top Roll
Forward/Reverse Dual Guarded Foot Switch
Sealed Anti-Friction Bearings On All Main Points
Large Aluminum Hand Wheels For Roll Adjustment
Emergency Stop Cable On Three Sides Of Machine
Overload Protection

F.O.B. Cincinnati, Ohio

Approximate Weight: 5200 Lbs.

FACTORY SPECIFICATION SUBJECT TO CHANGE AND/OR MODIFICATION
